Specification

माप सीमा
N/A (unless features onboard power meters)

सेंसर टाइप
N/A (unless equipped with current/voltage sensor)

पावर कंसम्पशन
Negligible (passive board)

एप्लीकेशन
Drone power management, hobby RC distribution

वायरलेस
,

विशेषताएँ
Compact design, easy to install, supports multiple ESCs

परिचालन तापमान
-20°C to 60°C

अंतरफलक
Solder Pads / XT60 input depending on model

सिग्नल का प्रकार
,

माउंटिंग टाइप
Through holes for screws or zip ties

रिस्पांस टाइम
Instantaneous

केबल की लंबाई
Dependent on user connection

प्रॉडक्ट टाइप
ESC Power Distribution Board

मटेरियल
Carbon Fiber

इनपुट
DC 2S-6S (7.4V ~ 22.2V) LiPo Battery

आउटपुट
4/6/8 ESC outputs (depends on model variant)

फंक्शन
Distributes power from battery to multiple ESCs and onboard components

उपयोग
Industrial

सटीकता
±0.05V (for onboard voltage detection, if available)

रेज़ोल्यूशन
Standard copper trace, 2oz thickness

वोल्टेज
Maximum 22.2V DC

वज़न
Approx. 10-20g

वारंटी
1 Year

Fire Retardant
No (Standard epoxy PCB material)

Color
Black with white silkscreen labels

PCB Thickness
1.6mm (standard for durability)

Heat Resistance
Yes, up to specified temperature threshold

Connector Type
Direct solder pads / XT60 input pad optional

Short Circuit Protection
No integrated protection

Number of ESC Outputs
4 main, with auxiliary pads for additional peripherals

Board Layer
2-layer PCB design

ESC Compatibility
Compatible with most brushless ESCs for drones

Fuse Protection
Optional, depends on the specific model

RoHS Compliant
Yes

Max Continuous Current
Up to 60A (depending on copper trace and board specification)

Mounting Hole Size
3mm diameter (standard for quadcopter frames)

Size/Dimensions
Approx. 36mm x 36mm

Trade Information

Minimum Order Quantity
1 Unit

आपूर्ति की क्षमता
प्रति महीने

डिलीवरी का समय
दिन

About

Unlock seamless drone power management with the masterfully engineered ESC Power Distribution Board-your gateway to a triumphant flight experience. Procure this renowned PCB for robust industrial, hobby RC, and quadcopter power distribution. Get direct solder pads with optional XT60 input, supporting up to 60A continuous current and up to 8 ESC outputs. Its 2-layer carbon fiber construction, compact size, and heat-resistant profile ensure supreme durability and easy installation. RoHS compliant and crafted for precision, this board sets a new standard for reliability and performance with a 1-year warranty.

Optimized Power Delivery for Drone Enthusiasts

The ESC Power Distribution Board is championed by drone hobbyists and professionals across India. Its application spans versatile industrial and recreational sectors, managing power delivery to multiple ESCs effortlessly. Its competitive advantages include a compact, lightweight design and compatibility with most brushless ESCs, ensuring reliability in demanding environments. Renowned among service providers, manufacturers, and suppliers, it is embraced for its durability and ease of use in quadcopters, RC vehicles, and DIY robotics projects.

Quality Certifications, Ready Stock & Expedited Dispatch

Our ESC Power Distribution Board is RoHS compliant, affirming its adherence to international safety and environmental standards. Samples are available on request, with ready stock ensuring quick fulfillment. Asking price is competitive for bulk and single-unit purchases in the main domestic market (India). Once ordered, units are dispatched promptly and securely, guaranteeing efficient delivery and customer satisfaction. Secure this high-demand board to elevate your drone power solutions today.

FAQ's of ESC Power Distribution Board:

Q: How do I connect ESCs to the distribution board?

A: You can connect up to 8 ESCs via designated solder pads or auxiliary pads. For input, use either direct solder pads or the optional XT60 input pad, depending on your model.

Q: What benefits does the ESC Power Distribution Board offer for drone applications?

A: It provides reliable power distribution to multiple ESCs, supports high current, and features a compact, lightweight design ideal for drones and RC hobby projects.

Q: When should I consider using a power distribution board of this type?

A: Use this board when you need to route safe, stable power from a LiPo battery (2S-6S) to multiple ESCs or peripheral devices in drones or RC models.

Q: Where is the ESC Power Distribution Board most commonly used?

A: It is widely used in drone builds, quadcopters, RC vehicles, industrial automation setups, and robotics projects requiring centralized power management.

Q: What is the process for requesting a sample?

A: To obtain a sample, simply contact the supplier or manufacturer via their official channels and specify your requirements. Stocks are generally ready to be dispatched upon confirmation.

Q: How does the board ensure safety and compliance?

A: The ESC Power Distribution Board is RoHS compliant, ensuring standard environmental safety. Some models offer optional fuse protection for added safety, though the standard model does not integrate short circuit or fire retardant features.
