Pixhawk Flight Controller
Pixhawk Flight Controller Specification
- Connectivity Type
- USB, Micro SD card, Serial, I2C, CAN, ADC, PWM
- Color
- Gray
- Usage
- Industrial
- Product Type
- Pixhawk Flight Controller
- Warranty
- 1 Year
- Camera Range
- Depends on external camera
- Camera Type
- Not applicable (external camera integration only), Supports external FPV or mapping cameras
- Sensor Type
- Accelerometer, Gyroscope, Magnetometer, Barometer, Accelerometer, gyroscope, magnetometer, barometer, external GPS/compass support
- Camera Style
- Not included (supports external camera modules), Supports external camera trigger and gimbal control (no built-in camera)
- Technology
- 32-bit ARM Cortex microcontroller, PX4 autopilot firmware, Mavlink telemetry, 32-bit ARM Cortex-M4 Processor, real-time operating system (NuttX)
- Special Features
- Open-source design, Real-time operating system, Redundant power supply, Integrated backup system, Multiple I/O ports, Advanced safety features, Open source hardware and firmware, high-precision IMU, multiple I/O ports, real-time operating system, redundant power supply inputs, integrated micro SD for logging
- Remote Control
- Compatible with multiple RC protocols including SBUS, PPM, DSM, and Futaba S.BUS, Supported via standard RC transmitter (PPM/SBUS/DSM/JR/Spectrum)
- Application
- Multirotor, Fixed-wing, Helicopter, Rover, Boat, Submarine UAVs and research projects, UAVs, drones, rovers, boats, and academic robotics projects
- Camera Size
- Not applicable (no built-in camera)
- Camera Pixels
- Not applicable (no built-in camera)
- Screen Resolution
- Not applicable (no built-in screen)
- Image/Video Quality
- Depends on external camera
- Power Supply
- Electric
- Output Formats
- PWM, SBUS, PPM, CAN, I2C, GPIO, UART
- File Compatibility
- Supports standard telemetry logs and data formats
- LED Indicators
- RGB status LED, buzzer output
- Expansion
- Micro SD card slot for onboard data logging and mission recording
- Operating Temperature
- -40°C to +85°C
- Barometer
- MEAS MS5611-01BA03 high-precision barometer
- Power Monitoring
- Integrated power management and monitoring
- Weight
- 38 grams (main controller only)
- IMU
- Triple redundant (L3GD20 gyroscope, ST Micro LSM303D accelerometer/magnetometer, Invensense MPU 6000 gyroscope/accelerometer)
- Firmware Updates
- Micro-USB for firmware loading and configuration
- Input/Output
- 14 PWM/servo outputs (8 with full redundancy, 6 auxiliary), 5 UARTs, 2 CAN ports, multiple I2C/SPI ports
- Firmware Compatibility
- PX4, ArduPilot compatible
- Safety Features
- Failsafe, arming and disarming switch support
- Dimensions
- 81 mm x 50 mm x 15 mm (approx.)
- Mounting
- Standard 30.5 mm x 30.5 mm and 45.0 mm x 45.0 mm mounting holes
- Processor
- 32-bit ARM Cortex-M4, 168 MHz, 256 KB RAM, 2 MB Flash Memory
- Telemetry
- Supports MAVLink telemetry via radio or USB
Pixhawk Flight Controller Trade Information
- Minimum Order Quantity
- 10 Units
- Supply Ability
- 1000 Units Per Month
- Delivery Time
- 7 Days
About Pixhawk Flight Controller
Buy Online the Pixhawk Flight Controller, a must-have for every UAV and robotics enthusiast seeking first-rate precision and eminent reliability. Powered by a majestic 32-bit ARM Cortex-M4 processor at 168 MHz with 256 KB RAM and 2 MB Flash, this controller features triple redundant IMUs and a high-precision barometer. Supporting 14 PWM outputs, five UARTs, multiple protocols, and advanced safety features, this unit guarantees excellent connectivity and control. Enjoy the benefit of Discount pricing, a 1 Year Warranty, and outstanding performance, fully compatible with PX4 and ArduPilot firmware.
Versatile Applications and Usage Directions
The Pixhawk Flight Controller is ideal for multirotor drones, fixed-wing aircraft, helicopters, rovers, boats, and even submarine UAVs. Its industrial-grade quality makes it suitable for research projects, academic robotics, and commercial drone operations. To use, simply mount using the standard hole patterns, connect sensors, configure with your desired firmware, and integrate with your remote control for seamless operation. Leverage its open-source flexibility for tailored applications and dynamic mission planning.
Global Markets, Best Rates, and Fast Delivery
The Pixhawk Flight Controller sees eminent demand across main export markets, including North America, Europe, and Asia, with India being a prominent domestic market. Order now to get the lowest price on this leading controller. Enjoy fast delivery times with Express Shipping options. Our service ensures quick dispatch, providing value for every rate paid with prompt, professional delivery. Secure your advanced flight controller today and experience world-class support, innovation, and efficiency.
Versatile Applications and Usage Directions
The Pixhawk Flight Controller is ideal for multirotor drones, fixed-wing aircraft, helicopters, rovers, boats, and even submarine UAVs. Its industrial-grade quality makes it suitable for research projects, academic robotics, and commercial drone operations. To use, simply mount using the standard hole patterns, connect sensors, configure with your desired firmware, and integrate with your remote control for seamless operation. Leverage its open-source flexibility for tailored applications and dynamic mission planning.
Global Markets, Best Rates, and Fast Delivery
The Pixhawk Flight Controller sees eminent demand across main export markets, including North America, Europe, and Asia, with India being a prominent domestic market. Order now to get the lowest price on this leading controller. Enjoy fast delivery times with Express Shipping options. Our service ensures quick dispatch, providing value for every rate paid with prompt, professional delivery. Secure your advanced flight controller today and experience world-class support, innovation, and efficiency.
FAQ's of Pixhawk Flight Controller:
Q: How do I install and configure the Pixhawk Flight Controller?
A: Begin by mounting the Pixhawk onto your UAV using the standard 30.5 mm x 30.5 mm or 45.0 mm x 45.0 mm patterns. Connect peripherals such as ESCs, GPS, external sensors, and configure your desired firmware (PX4 or ArduPilot) using the Micro-USB port for firmware loading and setup. Calibration and tuning are completed through compatible ground control station software.Q: What applications can the Pixhawk Flight Controller be used for?
A: Pixhawk is eminently versatile and designed for multirotor, fixed-wing, helicopter drones, rovers, boats, and submersibles, including both industrial and academic research applications. Its robust features make it suitable for UAVs, robotics projects, and experimental uses.Q: Where can I buy the Pixhawk Flight Controller online at a discount?
A: You can buy the Pixhawk Flight Controller online from reputed suppliers and service providers in India and globally. Look for promotional offers or seasonal discounts for the best value and secure authorized warranty coverage.Q: What are the main benefits of using this first-rate flight controller?
A: The Pixhawk offers advanced safety, real-time monitoring, triple redundant IMU sensors, high-precision barometer, and vast compatibility with open-source firmware. Users benefit from reliable, customizable, and scalable UAV control for both professional and experimental use.Q: Which remote control systems are supported by Pixhawk?
A: Pixhawk is compatible with many RC systems, including SBUS, PPM, DSM, Futaba S.BUS, and standard RC transmitters, ensuring wide usability with most industry-standard remotes.Q: When can I expect delivery if I use express shipping?
A: With express shipping, delivery times are significantly reduced, often within a few business days depending on your location. Check with your supplier for specific delivery estimates and tracking support.Tell us about your requirement
